Consulta

C9W

TPV Windows

Built for Stability, Compatibility, and The Flexibility to Configure What Your Operation Needs.

Póngase en contacto con
Descargar

C9 Family

C9W
TPV Windows
Built for Stability, Compatibility, and The Flexibility to Configure What Your Operation Needs.

Windows POS Machine Ideal for High-Demand Environments

15.6" 1080P FHD Screen

Modular
Lector de tarjetas

Intel® i3 Standard / i5 Optional

Rich I/O Ports

Up to 4.6 GHz Turbo

Identificación por huella dactilar

Tailor Logo

*Note: NFC reader and fingerprint ID are optional.

Windows POS Machine Ideal for High-Demand Environments

Wherever Businesses Happen, the C9W Is Ready.

The Right Processing Power for Every Type of Operation

Choose the processor tier that matches your workload — from a reliable i3 to a Ten-core i5 capable of parallel workflows simultaneously without lag.
standard

Intel® Core™ i3

Win 11 IOT LTSC Enterprise · High Compatibility

  • Reliable performance for full-service POS environments.
  • Broad Windows software ecosystem support.
  • Consistent thermal management for long operating hours.
Optional Upgrade

Intel® Core™ i5

Ten-Core · Up to 4.6 GHz Turbo

  • Handles concurrent workloads.
  • 4.6 GHz Turbo for instantaneous transaction processing.
  • Reduces wait time during peak-hour ordering surges.

Rich I/O That Connects Every Peripheral Your Operation Runs On

The C9W ships with a comprehensive I/O set including 6 USB ports and broad driver support eliminates the hunt for compatible scanners, printers, and card readers.

Full HD Clarity Where Every Transaction Counts

15.6″ with 1080P

Pantalla Full HD

Full HD clarity for menus, receipts, and loyalty screens.

350 nits

Alto brillo

Stays readable under bright retail environments.

170°

Campo de visión

Clear sight lines for staff and customers side-by-side.

A Windows POS Terminal Designed Thin, and Built for the Modern Counter

The C9W redefines what a Windows POS terminal looks like on the counter, delivering a near-borderless display that draws the eye and elevates the checkout environment. At just 8.75mm at its thinnest point, the profile is deliberate and modern.

5mm Bisel
80% Relación pantalla/cuerpo

16mm Espesor
8.75mm Parte más delgada

A Windows POS Terminal That Redefines What the Counter Looks Like.

A Touch-Enabled Customer Display to Extend the Interaction

Customers can confirm orders, apply loyalty points, or tip — directly on the secondary screen.

Two Reserved USB Ports on Customer Display

Connects every peripheral your business depends on.

A Touch-Enabled Customer Display to Extend the Interaction

Customers can confirm orders, apply loyalty points, or tip — directly on the secondary screen.

Two Reserved USB Ports on Customer Display

Connects every peripheral your business depends on.

Configure to Your Exact Requirements

The C9W is designed as a configurable touch screen billing machine — select the modules and features that match your workflow and brand.

More Display Options

High-Performance Android Option

For clients with Android-native software or development requirements, select Rockchip or Qualcomm platforms.

Telpo C9 >

Lector modular de tarjetas

Plug-and-play financial card reader module supports speedy payment processing.

Identificación por huella dactilar

Wake the terminal or log in as a named employee using a fingerprint, reducing unauthorized access risk.

Brand Logo Customization

Your brand mark on the terminal chassis — consistent across every location, every counter.

* Note: Tailored Solutions are all optional.

Solución a medida &
Diseño modular

Servicios de la Plataforma Telpo

Mejore la eficacia de la gestión de su negocio y sus beneficios con el TPV Telpo C9

Telpo MDMUna plataforma eficaz para la gestión de terminales
Telpo OSEl sistema operativo adaptado a los usuarios de Telpo
Telpo APP StoreProporcionar aplicaciones funcionales masivas
SDK de TelpoEficaz solución de desarrollo multiplataforma

Especificaciones técnicas

OS

Win 11 IOT LTSC Enterprise

Procesador

Intel® i3-1215U, Hexa-Core, Up to 4.4 GHz Turbo
Intel® i5-1334U, Ten-Core, Up to 4.6 GHz Turbo (Optioanl)

Memoria

8GB DDR, 128GB ROM
4GB DDR, 128GB ROM(Optional)
8GB DDR, 256GB ROM(Optional)

Mostrar

Pantalla principal 15,6", 1920*1080, táctil, G+G
Pantalla para el cliente: 10,1", 1280*800, soporte táctil, G+G (Opcional)
Pantalla del cliente: 15,6", 1920*1080, táctil, G+G (opcional)

Lector de tarjetas financieras (opcional)

NFC: ISO14443 Tipo A/B, Mifare (EMV Contactless L1, Paywave, Paypass certificado)
Tarjeta IC: ISO7816
Instalar en el lado de la pantalla de 10,1

Lector de tarjetas sin contacto (opcional)

ISO14443 Tipo A/B, Mifare (Bajo la segunda pantalla de 10,1")

Botón de huellas dactilares (opcional)

Ayuda

Comunicaciones

Wi-Fi / Bluetooth 5.0/ Ethernet

Puertos periféricos

6 USB-A(4*USB 2.0+2*USB 3.0)
1 RJ11(RS232)
1 RJ12
1 RJ45
1 puerto CC
2 Micro USB(10.1 Screen Extended Port) (Optional)

Audio

1 altavoz de 3 W
2 Micrófono (opcional)

Fuente de alimentación

24V/2.75A

Otros

1 Llave de encendido

MDM (opcional)

Gestión de dispositivos móviles

Medio ambiente

Temperatura de funcionamiento: -10℃ ~ 45℃
Temperatura de almacenamiento: -25℃ ~ 60℃

Certificación

CE, FCC, BIS
